processor
Dimensity 9200+ TSMC second-generation 4nm process CPU: octa-core processor, maximum frequency 3.35GHz GPU: Immortalis-G715 MC11
Frame inserting chip
Dedicated graphics chip X7 144FPS ultra-high frame rate 1.5K super resolution
Memory vs. capacity
24GB + 1TB Up to optional memory: 12GB / 16GB / 24GB storage: 256GB / 512GB / 1TB LPDDR5x RAM (up to 8533Mbps) UFS4.0 Flash (sequential read speed up to 4000MB/s)
Note: The actual usable capacity will decrease and vary due to many factors: because the operating system occupies part of the memory (RAM), the actual free space is less than the identified memory capacity; Since the installed operating system and pre-installed programs occupy part of the flash memory (ROM), the actual available storage space is less than the identified flash memory capacity.
Exterior dimensions
Height: 162.15mm Width: 75.7mm Thickness: 8.49mm Weight: 204g Note: The above data is Xiaomi laboratory test data, depending on the measurement method in the industry, the actual results may be slightly different.
Screen with fingerprint
1.5K high brightness high brush screen size: 6.67 inches Resolution: 2712*1220 Contrast ratio: 5,000,000 :1 Peak brightness: 2600nit Display frame rate: up to 144Hz Touch sampling rate: up to 480Hz UHF PWM dimming: up to 2880Hz 12bit color depth (687.3 billion colors)|DCI-P10 color gamut|professional primary color screen|ambient color temperature sensing|sunlight screen|classic eye protection|paper eye protection|HDR<>+|HDR Vivid|Dolby Vision|frame enjoy ultra-high definition|high-frequency PWM Dimming|Fingerprint under optical screen|Dark light unlock|Heart rate detection
Charge with battery
5000mAh (typ) built-in lithium ion polymer battery, non-removable Xiaomi surging P1 charging chip, Xiaomi surging G1 self-developed fuel gauge chip 120W wired fast charging mobile phone supports PD2.0 / PD3.0 fast charging protocol USB Type-C The double-sided charging interface comes standard with a 120W charger and is compatible with the PD charging protocol
Imaging system
Sony IMX800 Big Bottom Camera Sony Main Camera : 54MP/50MP (total/effective) sensor|OIS optical image stabilization|1/1.49" sensor|4in1 2.0μm fused pixels|7P lens|f/1.7 aperture 800 million pixels Ultra-wide lens: 119° FOV 200 million pixels Macro lens Xiaomi Image Brain 2.0 EIS Electronic Image Stabilization|Full Link P3|Everything Focus 2.0|AI Capture|HDR 10+|Film Camera|Film Frame|Moe Shooting 4.0|Portrait Ultra Definition Algorithm|Real-time Text Extraction|Document Mode 4.0|Movie Mode|Movie Filter|Voice Control Camera|Exposure Feedback|Timed Continuous Shooting|Magic Twin|Voice Subtitle|Live Photo|Micro Movie|AI Watermark|AI Camera|ID Card Copy Mode 8K Video Capture: 24FPS 4K Video Capture: 30/60FPS 1080p Video Capture: 30/60FPS 1080p Slow Motion Video Capture: 120FPS/240FPS/960FPS 720p Video Capture: 30FPS 720p Slow-motion video shooting: 120FPS/240FPS/960FPS front 2000MP HD portrait camera, Sony IMX596 Screen fill light|Volume key countdown to take photos|Super night scene|ultra-wide panorama|voice-activated photography|Time-lapse continuous shooting|Moe shooting 4.0|Micro movie|Time-lapse photography|Voice subtitles|Live photo|AI watermark|Portrait beauty|Face recognition|Video beauty|Kaleidoscope|Video tag 1080p Video shooting: 30FPS 720p Video shooting: 30FPS 1080p slow motion video shooting: 120FPS 720p slow motion video shooting: 120FPS
Networks and formats
Dual SIM 5G | Full Netcom 8.0 supports dual Nano-SIM card slots, unlimited operators can 5G network (5) Support mobile/Unicom/Telecom/Radio (4) 3G/2G/<>G/<>G (<>) Support dual SIM dual communication, dual SIM HD voice (<>).
Note (5): 2G support depends on the local carrier network; When two telecom cards are used, the non-network card needs to activate the HD Voice service, but it cannot be used if it is not activated or the local network does not support the HD Voice service. Note (3): Broadcast does not support 3G and 2000G networks; Radio and television do not support MMS services; Note (3): TD-SCDMA format (mobile 5G) is not supported; CDMA 5 EVDO format (Telecom 5G) is not supported; Note (4): Dual SIM only supports some frequency band combinations of <>G+<>G and <>G+<>G, and supports HD voice services of China Mobile, China Unicom, Telecom, and Broadcast, and the actual usage depends on the operator's local network and service deployment.
Support frequency band 5G: n1/n3/n5/n8/n28a/n66/n38/n41/n77/n78
Note: Actual network and band usage depends on local operator deployment; n28A (Tx:703-733MHz,Rx:758-788MHz)。
4G:FDD-LTE :B1/B3/B4/B5/B8/B18/B19/B26/B66 TDD-LTE :B34/B38/B39/B40/B41/B42
Note: LTE B41 (2496-2690 194MHz);
3G:WCDMA:B1/B4/B5/B6/B8/B19 2G:GSM:B3/B5/B8 ; CDMA 1X: BC0 supports 4x4 MIMO antenna technology "HPUE" HORxD
Data connection
WLAN protocols: Wi-Fi 6, Wi-Fi 5, Wi-Fi 4, and 802.11a/b/g WLAN frequency: 2.4G Wi-Fi | 5G Wi-Fi support 2x2 MIMO, Wi-Fi Direct, Miracast, 2.4G, 5G dual-socket concurrent Bluetooth Bluetooth 5.4 support: AAC/LDAC/LHDC 5.0/LC3/ASHA/Auracast
Navigation positioning
Beidou: B1I+B1C+B2a+B2b|GPS:L1+L5|Galileo:E1+E5a GLONASS:G1|QZSS:L1+L5|NavIC|A-GPS|Data Network Positioning|Wi-Fi Network Positioning| sensor Assisted Positioning
Video audio
Stereo two-speaker MP3, FLAC, AAC, OGG, WAV, AMR, AWB Hi-Res Audio Certified | Hi-Res Wireless Certification | Dolby Atmos MP4, MKV, AVI, WMV, WEBM, 3GP, ASF playback supports HDR10/10+ videos
sensor
Optical distance sensor|360° front and rear dual light sensor|acceleration sensor|ambient color temperature sensor|electronic compass|gyroscope|infrared remote control|Flicker sensor| X-axis linear motor
NFC capability
After the NFC-related services are activated in the wallet app, you can double-click the power button to use functions such as transportation card, Mi Pay, key card, and car key.
Packing list
Mobile phone host|power adapter|USB Type-C data cable|mobile phone protective case|film (covered on the screen)|pin|instruction manual (contains three packs of vouchers)
Special note: 1. In terms of memory and capacity, the actual available capacity will be reduced and different due to many factors: because the operating system occupies part of the memory (RAM), the actual free space is less than the identified memory capacity; Since the installed operating system and pre-installed programs occupy a portion of the storage (ROM), the actual available storage space is less than the identity storage capacity. 2. The screen drawings and product description display drawings provided by this website are all reference diagrams, and the actual situation is subject to the actual product. 3. Product pictures and models, data, functions, performance, specifications, user interface and other product information are for reference only, Redmi may improve the above content, please refer to the product physical and product manual for specific information. 4. The product station is not specifically pointed out, all are our laboratory data, design technical parameters and suppliers to provide data, the actual situation of the whole site data will be slightly different due to different test software versions, specific test environments, and specific versions. The structural pictures displayed by the whole site are functional diagrams, not absolute actual structures, and the final physical object shall prevail.
Remarks: * The structural pictures displayed on the whole site are all functional diagrams; Product pictures and display content are for reference only, actual product functions and specifications (including but not limited to appearance, color and size) and actual display content may vary, and the actual product shall prevail. * In terms of memory and capacity, the actual usable capacity will decrease and vary due to many factors: because the operating system occupies part of the memory (RAM), the actual free space is less than the identified memory capacity; Because the installed operating system and preinstalled programs occupy part of the flash memory (ROM), the actual available storage space is less than the identified flash memory capacity. * Product pictures and models, data, functions, performance, specifications, user interface and other product information are for reference only, Xiaomi may improve the above content, please refer to the product physical and product manual for specific information. Unless otherwise specified, the data on this website are Xiaomi's internal test results. * Product pictures, models, data, functions, performance, specifications, user interface and other product information may change due to factors such as product batch or supplier change, Redmi may improve the above content, please refer to the product physical and product manual for specific information.
