physical dimension
Length: 161.6mm Width: 73.9mm (folded) 144.7mm (unfolded) Thickness: 11.2mm (folded) 5.4mm (unfolded) Weight: 262g
*The above data is the test data of Xiaomi laboratory, and the actual results may vary slightly depending on the measurement method in the industry.
Memory Capacity
12GB+1TB Maximum optional running memory: 12GB LPDDR5 high-speed memory (6400Mbps) Body storage: 256GB / 512GB /1TB UFS 3.1 high-speed storage
* The actual usable capacity will be reduced and vary due to many factors: because the operating system occupies part of the memory (RAM), the actual usable space is less than the indicated memory capacity; because the installation of the operating system and pre-installed programs occupy part of the flash memory (ROM) ), the actual available storage space is less than the indicated flash capacity.
mobile platform
1st generation Snapdragon® 8+ mobile platform SoC process: 4nm process CPU frequency: Octa -core processor, maximum frequency up to: 3.2GHz GPU: Adreno ™ GPU Graphics processor AI: 7th generation AI engine
External screen 6.56 inches 21:9 standard ratio External screen type: flexible AMOLED Resolution: 2520x1080 Display frame rate: up to 120Hz primary color screen 2.0 AI Master Image Quality Engine Contrast 8,000,000: 1丨HDR10+丨Dolby Vision Full- screen Brightness: 1000nit Peak Brightness: 1400nit Internal Screen 8.02 -inch 2K+ Super Vision Screen Type: Eco² OLED Resolution: 2160x1914 Display Frame Rate: Up to 120Hz Primary Color Screen| LTPO 2.0 ⼁ DCI-P3|Classic eye protection / paper eye protection|360° photosensitive|Sunshine screen|Auto brightness 2.0 AI master image quality engine Contrast ratio 8,000,000:1丨HDR10+丨Dolby Vision full screen brightness: 1000nit Peak brightness: 1300nit
Battery life and charging
4500mAh
built-in parallel dual-cell high-energy density battery, non-removable USB Type-C double-sided charging interface , mobile phone supports QC4+/QC3+/QC3.0/QC2.0/PD3.0/PD2.0 fast charging protocol+MI FC 2.0 fast 67W wired second charge
imaging system
Leica Professional Optical Lens 50MP Ultra-thin Main Camera: Sony's IMX766|F/1.8 Large Aperture|Support 4-in-1 2.0μm Large Pixel Output| Support OIS Optical Image Stabilization|7P Full Coating 8MP 2x Telephoto: f/ 2.6 aperture|45mm equivalent focal length|Support Dual PD focusing , 13 million pixels, ultra-wide angle: f/2.4 aperture |Motion Capture|Short Video Recording|Portrait Mode|Panorama Mode| Pro Mode|Time Lapse|Cine Shot|Magic Clone|Super Night Scene 2.0|Document Mode|VLOG Video|Slow Motion Shot| AI Watermark|Long Exposure|AI Magic Kaleidoscope |AI Camera|Movie Mode|Portrait Blur Adjustment|AI Beauty|Ultra Wide Angle Edge Distortion Correction| ID Card Photocopying Mode|Voice Subtitles|Video Filters|Video Beauty|Video Super Stabilization|Dynamic Photos|Countdown Photo|Level Meter | Timed continuous shooting|Face recognition|HDR|Custom watermark|Voice-activated camera 8K video capture: 24fps 4K video capture: 30 / 60fps 1080P video capture: 30 / 60fps 720P video capture: 30fps Slow motion video capture: 720P 120fps / 240fps / 960fps slow-motion video shooting: 1080P 120fps / 240fps / 960fps front 20 million HD camera Dolby Vision | Short video recording | Portrait mode | Time-lapse photography | Voice subtitles | Video filters | Movie mode | Taking pictures|AI smart beauty|Portrait blur adjustment|Dynamic photos|Timed continuous shooting|Voice-activated photography Front video shooting frame rate 1080P video shooting: 30fps/60fps 720P video shooting: 30fps
network frequency
5G dual SIM 丨 All Netcom 7.0 supports dual Nano-SIM card slots, any operator can 5G network ①Support China Mobile/Unicom/Telecom 5G/4G/3G/2G ②Support dual SIM VoLTE HD voice ③
Note ①: Whether to support 5G depends on the local operator network; when two telecom cards are used, the secondary card can only be registered with the telecom VoLTE network, if the secondary card or the local network does not support telecom VoLTE services, it cannot be used;
Note ②: Not supported TD-SCDMA standard (Mobile 3G); does not support CDMA 2000 EVDO standard (Telecom 3G);
Note ③: VoLTE services of China Mobile/Unicom/Telecom are supported, and the actual usage depends on the operator's local network and service deployment.
Supported frequency bands 5G: n1 / n3 / n5 / n8 / n20 /n28 / n38 / n40 / n41 / n77 / n78 / n79 Supported by software upgrade after commercial release; 4G: FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/ B20/B26/B28 TDD-LTE: B34/B38/B39 /B40/B41/B42 Note: LTE B41 (2496-2690 194MHz); 3G: WCDMA: B1/B2/B4/B5/B6/B8/B19 2G:GSM:B2/B3/B5/B8;CDMA 1X:BC0 Support 4×4 MIMO Antenna Technology/HPUE/HO RxD
Data Connections
WLAN Protocols: WiFi 6 Plus, WiFi 5, WiFi 4 and 802.11a/b/g WLAN Frequency: 2.4G WiFi | 5G WiFi supports 2x2 MIMO, 8x8 Sounding for MU-MIMO, WiFi Direct, Miracast, 2.4G, 5G Dual Road Concurrent Bluetooth: Bluetooth 5.2 supports AAC/LDAC/LHDC/ASHA
Multifunctional NFC
After enabling NFC-related services in the wallet app, you can use functions such as transportation cards, Mi Pay, door cards, and car keys* by double-clicking the power button.
Navigation and positioning
Beidou: B1I + B1C+ B2a|GPS: L1 + L5|Galileo: E1 + E5a GLONASS: G1|QZSS: L1 + L5|NavIC: L5 AGNSS|Data network positioning丨Wi-Fi network positioning丨Sensor-assisted positioning
video audio
MP3, FLAC, APE, AAC, OGG, WAV, AMR-NB/AMR-WB, AWB Hi-Res & Hi-Res Wireless Audio Certification|Harman Kardon|Stereo Dual Speakers|Dolby Atmos| Audio Sharing丨Real-time ear feedback|WeChat/QQ call recording|HD recording 2.0 MP4, MKV, WEBM, 3GP Support high dynamic range display when playing HDR 10, HDR 10+, Dolby Vision video content
sensor
Under-screen ambient light sensor ⼁ accelerometer ⼁ Hall sensor|fingerprint sensor|under-screen optical distance sensor|gyroscope ⼁ electronic compass|linear motor ⼁ infrared remote controller ⼁ barometer ⼁ rear light (color temperature) sensor ⼁ Flicker sensor
operating system
MIUI Fold
packing list
Mobile phone host socket power adapter socket USB Type-C data cable Type - C to Audio adapter cable bracket protective case |
*This list is only for the packaging of the whole machine. According to different sales packages, the accessories packages provided outside the whole machine packaging are slightly different, which is subject to the user's choice at the time of purchase.
Special instructions: *In terms of memory and capacity, the actual available capacity will be reduced and different due to many factors: because the operating system occupies part of the memory (RAM), the actual available space is less than the marked memory capacity; due to the installation of the operating system and pre-installed The program occupies part of the flash memory (ROM), and the actual available storage space is less than the indicated flash memory capacity. * Typical 500nit screen brightness inside and outside the screen, the maximum brightness of the full screen is 1000nit. *In terms of charging, data such as speed and duration are all our laboratory data, and the actual situation may vary slightly depending on the version of the test software and the specific test environment. In the end, the actual usage time shall prevail. *The screen diagrams and product description diagrams provided on this website are all reference diagrams, and the actual situation shall prevail in kind. *Product pictures, model, data, function, performance, specifications, user interface and other product information are for reference only. Xiaomi may improve the above content. For specific information, please refer to the actual product and product manual. Unless otherwise specified, the data involved in this website are the results of internal testing by Xiaomi, and the comparisons involved are all compared with Xiaomi products. *The general mobile phones compared on the page are Xiaomi's own mobile phones. Unless otherwise specified, the product site is provided with data from our laboratory, design technical parameters and suppliers. The actual situation of the data on the whole site may vary slightly depending on the test software version, specific test environment and specific version. The structural pictures displayed on the whole site are all functional schematic diagrams, not the absolute actual structure, and the actual object shall prevail. *There are slight creases in the bending area of the inner screen of the mobile phone, and there is a sound during the opening and closing of the mobile phone, which is a normal phenomenon, please use it with confidence. *During use and carrying, please avoid sharp objects (pen tips, nails, etc.) from pressing the inner screen. Before folding the screen, do not place cards, coins, keys, etc. on the screen. *Contains precision components, in order to prolong the service life, do not expose the mobile phone to liquid, sand and other environments to avoid foreign objects entering the device. *The inner screen comes with a specially designed special protective film, please do not tear off or paste other protective films by yourself, otherwise it will damage the screen and affect the warranty. If you need to replace the protective film, please consult Xiaomi after-sales.
