OnePlus 13 - Specifications White dew and morning light
Exterior dimensions
Height: 162.9mm
Width: 76.5mm
Thickness: 8.9mm (leather) 8.5mm (glass)
Weight: Approx. 210g (leather) 213g (glass)
Processing platform
Platform: Qualcomm Snapdragon ®8 Ultra Mobile Platform
SoC process: second-generation TSMC 3nm process
CPU Frequency: Octa-core processor, up to 4.32GHz
GPU : Adreno™ 830 GPU graphics processor
AI: A new generation of AI engines
storage
RAM: 12GB/16GB/24GB LPDDR5X
Body Storage (ROM): 256GB/512GB/1TB UFS 4.0
Configuration combination: 12GB+256GB/12GB+512GB/16GB+512GB/24GB+1TB
screen
Size: 6.82 inches
Screen type: Congruent depth soft edge straight screen
Screen-to-body ratio: 93.1%
Resolution: QHD+ (3168×1440)
Pixel density: 510PPI
Refresh rate: up to 120Hz, 1-120Hz adaptive refresh
Brightness: 800nit (typical), 1600nit (HBM), 4500nit (peak brightness)
Low flicker mode: Bright eyes low flicker, classic low flicker, full brightness low flicker
Screen color: 1.07 billion colors (10bit)
Color Gamut:
Natural Mode: Overrides 100% DCI-P3 with color management
Pro Mode: Covers 100% DCI-P3 with color management
Vivid Mode: Covers 100% DCI-P3 with color management
AOD Support: Yes
Eye protection mode: Support low flickering of bright eyes, which is turned on by default
Functions: Eye Protection Mode, Sleep Mode, Bright Eyes Low Flicker, Full Brightness DC-like Dimming, Sun Display
Battery & Charging
Wired fast charging: 100W super flash charging
Wireless fast charging: 50W wireless flash charging
Wireless Reverse Charging: Yes (Max Power 10W)
Wired Reverse Charging: Yes (Max Power 5W)
Battery: Dual-cell equivalent 6000mAh (non-removable)
Power management chip: Full-link power management chip
camera
postposition
50-megapixel main camera: ƒ/1.6, 23mm-equivalent focal length, seven-element lens, AF support, two-axis OIS support
50-megapixel telephoto camera: ƒ/2.6, 73mm-equivalent focal length, four-element lens, AF-enabled, two-axis OIS support
50-megapixel ultra-wide-angle camera: ƒ/2.0, FOV 120°, 15mm-equivalent focal length, six-element lens, AF support
Zoom: Supports up to 3x optical zoom and up to 120x digital zoom
EIS Electronic Image Stabilization: Yes
Flash: Rear LED monochromatic temperature dual light
Rear Features: Photo, Video, Portrait, Night Scene, Master, High Resolution, Panorama, Movie, Slow Motion, Time Lapse, Long Exposure, Multi-Scene Video, Cute Shot, AI ID Photo, Document, Tilt Shift, XPAN
Photo formats: JPEG (default), HEIF, RAW
Front-loaded
32-megapixel camera: ƒ/2.4, 21mm-equivalent focal length, five-element lens
Front functions: photo, video, night scene, panorama, portrait, time-lapse, multi-view video, cute shot, AI ID photo
Photo formats: JPEG (default), HEIF
Video shooting
postposition
8K video shooting: 30fps
4K video shooting: 60fps, 30fps
1080P video shooting: 60fps, 30fps
720P video shooting: 30fps
Video stabilization: EIS/OIS, 4K (60fps, 30fps), 1080P (60fps, 30fps)
Video zoom shooting: 4K (60fps, 30fps), 1080P (60fps, 30fps), 720P (30fps)
Slow motion video shooting: 1080P (240fps), 720P (480fps, 240fps)
Dolby Vision shooting: 4K (60fps, 30fps), 1080P (60fps, 30fps)
Cinematic mode shooting: 4K (30fps)
Time-lapse shooting: 4K (30fps), 1080P (30fps)
Multi-view video recording: 1080P (30fps)
Slow Motion Shooting: 1080P (240fps), 720P (480fps, 240fps)
Video shooting: Up to 3x optical zoom, up to 18x digital zoom
Front-camera
4K video shooting: 60fps, 30fps
1080P video shooting: 60fps, 30fps (default, beautify enabled)
720P video shooting: 30fps
Video stabilization: 1080P (30fps) (default, beautify enabled), 720P (30fps)
Dolby Vision shooting: 4K (60fps, 30fps), 1080P (60fps, 30fps)
Support multi-view video, time-lapse photography
Networks & Connectivity
Cellular networks
LTE antenna and RF technology: 4×4 MIMO; Band 1/3/4/39/38/40/41/66/42/48 4×4 MIMO;
Other Bands: 2×2 MIMO
Band
2G GSM：850/900/1800MHz
3G WCDMA：Bands 1/4/5/8
4G LTE FDD：1/3/4/5/7/8/18/19/20/26/28A/66
4G LTE TDD：Bands 34/38/39/40/41/42/48
5G：n1/n3/n5/n7/n8/n20/n28A/n38/n40/n41/n48/n77/n78/n66/n83A
5G dual-mode: SA/NSA dual-mode, supporting 5G dual-SIM dual-standby dual-pass
Support VoLTE carriers: Mobile, China Unicom, and radio and television VoLTE are supported
Instructions for using dual SIM:
1. The full Netcom version of the mobile card can be used with China Unicom card and telecom card at will, the main and auxiliary cards all support 5G, and any card can be used as a network card.
2. When two telecom cards are inserted, the non-network card must enable VoLTE service and enable VoLTE HD call, and the operator's network must support 4G VoLTE service to use dual telecom cards, otherwise, the two telecom cards cannot be used at the same time.
Note: Actual network and band usage depends on local carrier deployment.
Wi-Fi WLAN protocols: Wi-Fi 2.4G, Wi-Fi 5G, Wi-Fi 7 (802.11be), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), and 802.11b/g/a/n
WLAN frequency: support WLAN 2.4G, support WLAN 5.1G, support WLAN 5.8G
Network overlay: Wi-Fi 2.4GHz 2x2 + Wi-Fi 5GHz 2x2 concurrency
Support WLAN Display and WLAN network sharing
Supports Wi-Fi 2.4GHz 20M, Wi-Fi 2.4GHz 40M, Wi-Fi 5GHz 20M, Wi-Fi 5GHz 40M, Wi-Fi 5GHz 80M, and Wi-Fi 5GHz 160M
Supports 2x2 MIMO; Supports 8 Spatial-stream sounding MU-MIMO
Location features Dual-band support: BeiDou (B1I+B1C+B2a), GPS (L1+L5), GLONASS (G1), Galileo (E1+E5a), QZSS (L1+L5)
Other: Support A-GNSS assisted positioning, wireless LAN positioning, cellular network positioning
Bluetooth Bluetooth 5.4, Bluetooth Low Energy
Support Bluetooth sharing network
Bluetooth audio specifications: support SBC, AAC, aptx, aptx-HD, LDAC, LHDC (5.0)
Multi-function NFC NFC function: support reading and writing NFC cards (13.56MHz NFC cards)
NFC-SIM support (SIM1 card slot only)
Support for HCE
Support eSE (support 300+ city subway bus rides, support OnePlus Pay, access control card, car key and citizen network electronic identity (eID) and many other functions. With a single touch, convenient passage and secure payment. ）
VoLTE: Yes
Video calls: Yes
audio
Ultra-linear stereo dual speakers
Four-microphone AI noise cancellation
OReality Audio
Material
Screen protection glass: crystal shield super ceramic crystal glass
Middle frame: aluminum alloy metal middle frame
Back material: glass, leather
interface
SIM card: Support SIM card contact import and export
USB port type: Type-C port
Standard Type-C headphones are supported
USB version: USB 3.2 Gen 1
operating system
ColorOS 15.0 is based on Android 15
Packing list
OnePlus 13
Charger ×1
Cable ×1
SIM Cartoon Pin ×1
Quick Start Guide ×1
Protective case ×1
remark
1. The description of the relevant product parameters in the relevant pages has been remarked on the corresponding pages, so it will not be repeated here, and the details are specified on each page;
2. The weight of the bare metal (without film) is about 213g (glass) and 210g (leather), and the size and weight of the mobile phone may vary according to the configuration, manufacturing process and measurement method;
3. The display has rounded corners, and when measured in a standard rectangular shape, the diagonal length of the screen is 6.82 inches (the actual viewing area is slightly smaller). The resolution corresponds to the standard rectangle, and the actual screen has slightly fewer effective pixels;
4. Because the phone's software takes up some space, including Android and pre-installed apps, the amount of memory that can be used on the phone is less than this value. Storage capacity varies based on software version and may vary by device;
5. There may be differences in the pixels of photos with different photo modes, please refer to the actual situation. There may also be differences in the pixels of videos in different shooting modes, please refer to the actual situation.
6. The battery adopts a series dual cell design, typical capacity: 3000mAh (7.64V), equivalent to 6000mAh (7.64V), typical energy: 22.92Wh. Rated capacity: 2920mAh (7.64V), equivalent to 5840mAh (7.64V), rated energy: 22.31Wh. The data is based on the official laboratory calculations, due to personal habits, machine aging and other factors, the experience may be different, please refer to the actual experience. 100W UFCS Fusion Fast Charging means that the phone supports up to 100W UFCS Fusion Fast Charging, which must be paired with a charger certified by OPPO Fast Charging. Chargers that are not certified by OPPO Fast Charge support up to 44W UFCS fusion fast charging;
7. The product pictures and content on the page are for illustration only, the physical product effect (including but not limited to appearance, color, size) and screen display content (including but not limited to background, UI, and pictures) may be slightly different, please refer to the actual product, welcome to offline stores across the country to experience, store address query link: https://www.oneplus.com/cn/retail;
8. The data on the page are theoretical values, which are provided by suppliers or from official laboratories and obtained in a specific test environment (see specific instructions), and may be slightly different in actual use due to individual product differences, software versions, use conditions and environmental factors, please refer to the actual experience;
9. Due to real-time changes in product batches and production and supply factors, in order to provide as accurate product information, specifications, and product features as possible, OnePlus may adjust and revise the text expressions, image effects, and other content on the above pages in real time to match the actual product performance, specifications, indexes, components, and other information. If it is necessary to modify or adjust the page, no special notice will be given.
10. The operating system information is for reference only, and the actual product shall prevail. It is subject to change without notice.
Remark:
1. The OnePlus 13 is waterproof and dustproof under normal use. Under controlled laboratory conditions, the effect has been tested to reach IP69 and IP68 levels under GB/T 4208-2017 (domestic) standards. Among them, the IPX9 waterproof test conditions are: (1) turntable speed: (5±1) r/min; (2) Spray angle: 0°, 30°, 60°, 90°; (3) Flow: (15±1) L/min; (4) Water temperature: (80±5) °C; (5) Test time: 30s/each angle; (6) Mobile phone placement: Horizontal placement, screen up. Among them, the IPX8 waterproof test conditions are: (1) no flowing clear water, water depth of 1.5 meters; (2) The test time is 30 minutes; (3) The difference between the water temperature and the product temperature is not more than 5 degrees Celsius. Do not charge your mobile phone in a humid state, there are differences between the living scene and the experimental environment, and do not immerse the mobile phone in water or contact it with solutions such as seawater or liquids such as drinks during daily use. After raining/soaking/splashing, the liquid may block the sound/radio pipes of the microphone, earpiece, and speaker, resulting in abnormal listening/recording during calls and playback. The waterproof and dustproof function may be degraded due to wear and tear in daily use.
2. The data of the Snapdragon 8 Ultra mobile platform comes from Qualcomm Snapdragon official information. Performance may be affected by environmental factors such as time limit, battery level, and brightness.
3. The Antutu benchmark test data comes from OnePlus Labs, and the test model is OnePlus 13 24GB+1TB version, which passed the Antutu V10 test. The data may differ depending on the test environment, method, memory specifications, software version, and other conditions.
4. OnePlus 13 is available in three memory versions of 12GB, 16GB, and 24GB, and three flash versions of 256GB, 512GB, and 1T. For example, if a photo is 4MB in size, up to 1TB of storage can easily hold about 200,000 photos. The 4-year fluency test data comes from OnePlus Labs, and the experience is based on reality.
5. The heat dissipation capacity data and performance are calculated by the official laboratory, and the experience may vary due to factors such as machine aging, network environment, and personal usage habits.
6. The game data is calculated based on the official laboratory, and the game performance may vary due to factors such as machine aging, network environment, personal usage habits, etc., please refer to the actual experience.
7. The three rear cameras of OnePlus 13 are all 50 million pixels, the data comes from official lab reports or provided by suppliers, and the shooting effect is affected by shooting technology, ambient brightness, etc., please refer to the actual experience. There may be differences in the pixels of photos with different photo modes, please refer to the actual situation. Video pixels may vary depending on the shooting mode, please refer to the actual experience.
8. The display has rounded corners, and when measured as a standard rectangle, the diagonal length of the screen is 6.82 inches (the actual viewing area is slightly smaller).
9. The screen resolution is 3168 × 1440, the resolution corresponds to the standard rectangle, and the actual screen has slightly fewer effective pixels.
10. The brightness data is from OnePlus Labs, and there may be an error of ±5% in actual testing.
11. OnePlus 13 has passed the TÜV Rheinland Smart Eye Care High Visibility Certification.
12. OnePlus 13 has passed TÜV Rheinland Smart Eye Care 4.0 certification, which takes care of your eyes from the dimensions of screen display quality, hardware low blue light filtering, eye protection technology, ambient light management, health and comfort guidelines, etc. This product is not a medical device and has no therapeutic function.
13. 110ms ultra-fast unlocking, which refers to the time it takes for the system to successfully recognize the fingerprint, excluding the desktop animation after unlocking, etc., the data comes from OnePlus's official laboratory.
14. Support gloves with a thickness of no more than 5mm in the market, such as cotton, wool, sheepskin and other material gloves. When using, touch and slide the screen with your fingertips, and try to avoid a large gap between the gloves and your fingers, so that the screen will not be able to recognize your finger movements. If you're using thick gloves or if there's a gap between your fingertips and the glove, the screen may not be able to detect your finger movements.
15. This battery is designed with two cells in series, typical capacity: 3000mAh, equivalent to 6000mAh; Rated capacity: 2920mAh, equivalent to 5840mAh. The data is based on the official laboratory calculations, due to personal habits, machine aging and other factors, the experience may be different, please refer to the actual experience.
16. The battery life (DOU) data comes from official laboratory tests, due to different factors such as machine aging, network environment, personal usage habits, etc., the experience may be different, please refer to the actual experience.
17. OnePlus 13 can support wired 100W charging up to 100W, wireless 50W charging up to 50W, wired and wireless standard power adapters up to 100W and 50W respectively, wireless power adapter sold separately.
18. Charging time data is from official lab reports. Test environment: Initial battery temperature 25±1°C, ambient temperature 25±1°C. Test conditions: Turn off all background running programs, turn on airplane mode, and use the standard power adapter to charge with the screen off when the phone battery is 1%. Actual charging speed may vary depending on device usage, charging conditions, and other factors; The test data is for reference only, and everything is subject to actual experience.
19. The scope of AI voice summarization support is subject to actual experience. Depending on the language, accent, environment, network environment, personal usage habits and other factors, the actual experience effect will dynamically change with different scenarios.
20. This feature will be updated with subsequent ColorOS 15 releases.
21. The 400-meter ultra-long-range environment is an open and interference-free environment, and the ultra-long-range Bluetooth needs to be used with OPPO/OnePlus earphones, and the specific applicable models may have different effects. The data obtained by ultra-long-range Bluetooth comes from OnePlus Bluetooth Lab.
22. The functional performance of NFC is based on the official laboratory calculation, and the experience may vary due to different personal usage habits, usage environment and other factors, please refer to the actual experience.
23. The data comes from OnePlus's official laboratory, and the test of 20 apps was launched in two consecutive rounds, and the test was carried out in the state of background emptying, and the measured effect reached the 20 apps with 0 flashbacks, 0 flashes, 0 frame drops, 0 delays, and 0 disconnections after two consecutive rounds of startups. Due to different factors such as software and hardware technology optimization, network environment, and personal usage habits, the actual experience effect will change dynamically with different scenarios.
24. Please refer to the actual experience of the device models and application service types supported by Fluid Cloud. Some product/service information is provided by third parties, and OnePlus does not guarantee the authenticity, accuracy and completeness of any information, content, advertising and other information (hereinafter collectively referred to as "Information") of third parties, except as expressly provided by laws and regulations. Some of the information may contain links to third-party websites, products, and services.
25. Please refer to the actual experience for the scope of application of free split-screen support.
Disclaimer:
1. The weight of the bare metal (excluding film) is about 210g for the leather version and 213g for the glass version, and the size may vary depending on the configuration, manufacturing process, and measurement method.
2. Because the mobile phone software takes up part of the space (including the Android system and pre-installed APP), the memory capacity that the mobile phone can use is less than this value. Storage capacity varies based on software version and may vary by device.
3. The data on the page is a theoretical value, which is provided by the supplier or from the official laboratory, and obtained in a specific test environment (see each specific description), and the actual use may be slightly different due to individual product differences, software versions, use conditions and environmental factors, please refer to the actual experience.
4. If there is no special note, the content of the product interface shown on the above page (including but not limited to UI and background) is only for function display, each function belongs to different software versions, and the online time and region of different software versions are different, please refer to the actual version functions and interface. AI-related capabilities may vary depending on factors such as software version, environment, network environment, and personal usage habits.
5. The product pictures and content on the page are for illustration only, the physical product effect (including but not limited to appearance, color, size) and screen display content (including but not limited to background, UI, and pictures) may be slightly different, please refer to the actual product, welcome to offline stores across the country to experience, store address query link:
https://www.oneplus.com/cn/retail.
6. Due to the real-time changes in product batches and production and supply factors, in order to provide as accurate product information, specifications, and product characteristics as possible, OnePlus may adjust and revise the text expressions, picture effects, and other contents on the above pages in real time to match the actual product performance, specifications, indexes, parts, and other information. If it is necessary to modify or adjust the page, no special notice will be given.
This product has passed China RoHS conformity assessment
