Remark
one plus 11
physical dimension
Height: 163.1mm
Width: 74.1mm
Thickness: 8.53mm
Weight: about 205g
processing platform
Platform: Qualcomm 2nd Generation Snapdragon® 8 Mobile Platform
SoC process: TSMC 4nm process
CPU main frequency: octa-core processor, the highest main frequency is 3.2GHz
GPU: Adreno™ 740 GPU graphics processing unit
store
Running memory (RAM): 12GB/16GB LPDDR5X
Body storage (ROM): 256GB/512GB UFS4.0
Configuration combination: 12GB+256GB | 16GB+256GB | 16GB+512GB
Screen
Dimensions: 6.7 inches
Screen type: Samsung 2K+120Hz AMOLED flexible slightly curved screen
Screen ratio: 20.1:9
Screen ratio: 92.7%
Screen resolution: 3216*1440 (QHD+)
Pixel density: 525 PPI
Contrast ratio: static up to 5000000:1 (typical value), dynamic up to 12000000:1 (typical value)
Screen refresh rate: 1-120Hz adaptive refresh rate
Global default maximum brightness: 500nit typical value
Global excitation maximum brightness: 800nit typical value
Local peak maximum brightness: 1300nit typical value
AOD support: support
Functions: AI brightness adaptive adjustment, multi-brightness color calibration, LTPO 3.0 dynamic frame change, Dolby Vision, 1Hz AOD, ambient color adaptation, image quality ultra-clear enhancement, video color enhancement, eye protection mode, screen color mode, Screen color temperature adjustment, HDR video highlight mode, dark mode
battery and charging
Wired fast charge: 100W super flash charge
Battery: non-removable, double battery equivalent to 5000mAh battery energy
camera
rear camera
Main camera: 50 million pixels, all-pixel omnidirectional focusing; f/1.8; FOV 84°; 6P lens; supports AF; adopts closed-loop focus motor, supports OIS optical image stabilization.
Ultra wide-angle camera: 48 million pixels, f/2.2; FOV 115°; 6P lens, supports AF; supports 3.5cm macro shooting.
Telephoto camera: 32MP, 2x optical zoom; f/2.0; FOV 49°; 6P lens; supports AF.
Optical zoom: support 2x optical zoom, support 20x digital zoom
OIS: Support OIS optical image stabilization
Flick Sensor: support
PDAF: support
Flash: Rear LED single color temperature dual lights
rear video
Rear supports 8K @24fps, 4K@60fps/30fps, 1080P @60fps/30fps, 720P@60fps/30fps;
Video stabilization supports EIS/OIS, 1080P @60fps;
Video zoom shooting supports 4K@30fps, 1080P @60fps/30fps, 720P@60fps/30fps;
Video slow motion supports 1080P @240fps, 720P@240fps/480fps;
Movie mode supports 4K@30fps;
Time-lapse photography supports 4K@30fps, 1080P@30fps;
Multi-view recording supports 1080P@30fps;
post function
Photo, video, night scene mode, professional mode, panorama mode, portrait mode, time-lapse photography, slow motion, super text, movie, long exposure, multi-view video, tilt-shift, XPan, scan, cute shot, AI ID photo , auto macro function, etc.
Front camera
16MP, f/2.4; FOV 82°; 5P lens
front video
The front supports up to 1080P/720P@30fps, and the default is 1080P@30fps (beauty is turned on by default)
Front supports video anti-shake 1080P@30fps
front function
Photos, videos, panoramas, portraits, night scenes, time-lapse photography, multi-view video, cute shots, beauty, screen fill light, etc.
network and connection
LTE/LTE-A
4×4 MIMO; Band1/3/38/39/40/41 4×4 MIMO; other Bands: 2×2 MIMO
Support 4×4 MIMO Antenna Technology | HPUE | HO RxD
frequency band
GSM: 850/900/1800/1900MHz
CDMA:BC0
WCDMA: Bands 1/2/4/5/8
LTE FDD: Bands 1/2/3/4/5/7/8/12/17/18/19/20/26/28A/66
LTE TDD: Bands 34/38/39/40/41
5G NR: n1/n3/n5/n7/n8/n20/n28A/n38/n40/n41/n66/n77/n78
Remarks: The actual network and frequency band usage depends on the deployment of local operators.
Wi-Fi
Support Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), 802.11a/b/g/n/;
WLAN 2.4G/WLAN 5.1G/WLAN 5.8G;
Support WLAN Display; WLAN network sharing;
Support network overlay: Wi-Fi 2.4GHz 2×2 + Wi-Fi 5GHz 2×2 concurrent;
Support Wi-Fi 5GHz 160MHz;
Support 2×2 MIMO; 8 Spatial-stream sounding MU-MIMO
Bluetooth
Bluetooth 5.3, Bluetooth Low Energy
navigation
Support Beidou: B1I+B1C+B2a; GPS: L1+L5; GLONASS: G1; Galileo: E1+E5a; QZSS: L1+L5
NFC
Full-featured NFC
Support reading and writing NFC card (13.56MHz NFC card)
Support HCE
Support eSE (support 300+ city subway bus rides, support OnePlus Pay, access control card, car key and many other functions. One touch, convenient and safe payment.)
VoLTE: support
Video call: support
audio
super linear speaker
dual microphone
Support Dolby Atmos
Support for spatial audio
sensor
fingerprint unlock
G-sensor
Electronic compass
Gyro
rear color temperature sensor
Rear 13-channel multispectral sensor
Proximity sensor
Qualcomm Sensor Core
Support SAR function
Customized super large X-axis linear motor (bionic vibrating motor)
material
Screen protection glass: Corning® Gorilla® Glass 7
Middle frame: aluminum alloy metal middle frame
Back Material: Glass
interface
USB interface type: Type-C interface
USB version: USB 2.0
SIM card: Dual Nano-SIM card
Micro SD: not supported
operating system
System version: ColorOS 13.0 based on Android 13
packing list
one plus 11
Data cable (USB A to Type C)
Charger (100W SUPERVOOC Adapter)
SIM card pin
protective case
Quick Start Guide
safety guide
brand stickers
Side Hole Sticker
welcome letter
Remark
1. The relevant product parameter descriptions on the relevant pages have been remarked in the corresponding pages, so they will not be repeated here. For details, please refer to the specific instructions on each page;
2. The weight of the bare phone (without film) is about 205g, and the size and weight of the phone may vary depending on the configuration, manufacturing process and measurement method;
3. The display is designed with rounded corners. When measured according to a standard rectangle, the diagonal length of the screen is 6.7 inches (the actual viewing area is slightly smaller). The resolution corresponds to a standard rectangle, and the actual screen has slightly fewer effective pixels;
4. Since the mobile phone software occupies part of the space (including the Android system and pre-installed apps), the available memory capacity of the mobile phone is less than this value. Storage capacity varies based on software version and may vary by device;
5. There may be differences in the photo pixels of different camera modes, please refer to the actual situation. There may also be differences in the video pixels of different shooting modes, please refer to the actual situation;
6. Using 2*2500mAh series double cells (2500mAh is the typical value of single battery capacity), the typical capacity is equivalent to 5000mAh battery energy;
7. The product pictures and content on the page are for illustration only, the actual product effect (including but not limited to appearance, color, size) and screen display content (including but not limited to background, UI, picture) may be slightly different, please refer to The actual product shall prevail, and you are welcome to go to offline stores all over the country to experience it. The store address query link: https://www.oneplus.com/cn/retail;
8. The data on the page are theoretical values, all provided by the supplier or from the official laboratory, and obtained in a specific test environment (see the specific instructions). In actual use, there may be differences between individual products, software versions, conditions of use and The environmental factors are slightly different, please refer to the actual experience;
9. Due to real-time changes in product batches and production and supply factors, in order to provide as accurate product information, specifications, and product features as possible, OnePlus may adjust and revise the text expressions, picture effects, etc. The actual product performance, specification, index, parts and other information match; if there is a need to modify and adjust the page, no special notice will be made.
1. The performance fluency experience may be affected by environmental factors such as usage time limit, power consumption and brightness. Please refer to the actual experience;
2. The 16GB ultra-large memory is limited to 16GB+256GB and 16GB+512GB versions. The memory comparison data is LPDDR5X vs. LPDDR5, and the flash memory comparison data is UFS 4.0 vs. UFS 3.1. The data is based on official laboratory calculations. Due to machine aging, network environment, Due to different personal usage habits and other factors, the experience may be different, please refer to the actual experience;
3. With its excellent fluency, OnePlus 11 has obtained the 48-month fluency grade A certification of South Germany and the SGS human fluency A+ certification. The data is based on official laboratory calculations. Due to factors such as machine aging, network environment, and personal usage habits, the fluency experience may vary. Please refer to the actual experience;
4. The super-frame super-picture engine now supports super-score for 100+ 120-frame games. In addition, the super-frame super-picture engine also supports super resolution and HDR game quality experience. The data is based on official laboratories or suppliers. Please refer to the actual experience;
5. The game cloud computing private network data is calculated based on official laboratory calculations. (1) Based on professional human factors research, 110ms is the critical value for users to experience network delay; when it is more than 120ms, the user experience is generally unsatisfactory; when it is more than 230ms, users cannot Continue the game. For highly sensitive players, the impact will be more significant. (2) Field test method (taking dual-channel dual-transmission as an example): Two OnePlus 11s with the same software version and the same operator’s SIM card are placed in card slot 1 and placed side by side at the same position and at the same time. Connect to the same weak signal WiFi network, enter the same game of King of Glory, and use the data capture tool to record data at the same time. Machine 1 turns on OPPO Smart Cloud Acceleration, and Machine 2 turns off OPPO Smart Cloud Acceleration. (3) The concept of delay times: Based on the test method of taking 1 value at intervals of 1 second in the test, N times of delay means that there are a total of N times in this game to take the value of the delay state (higher than 110ms). The total duration of a game is calculated as 30 minutes. Due to factors such as machine aging, network environment, and personal usage habits, the fluency experience may vary. Please refer to the actual experience; the game cloud computing network currently supports mainstream games (Glory of the King, League of Legends mobile games, Peace Elite , Yuanshin), users who purchase OnePlus 11 can enjoy 2 years of free gaming cloud computing private network experience. The 2-year period refers to the calculation starting from the time when each mobile phone receives the OPPO Smart Cloud acceleration rights. After the expiration of 2 years, purchase OPPO Smart Cloud Acceleration in the game assistant to continue to use;
6. The data is based on official laboratory calculations. Due to factors such as machine aging, network environment, and personal usage habits, the game experience may vary. Please refer to the actual experience;
7. The relevant data of the bionic vibrating motor comes from the official laboratory report. The volume of the motor is increased by 67% for comparison with OnePlus 10 Pro. Due to different usage scenarios, personal usage habits and other factors, the actual experience may be different;
8. The relevant data of the speaker comes from the official audio laboratory report. Due to different factors such as usage scenarios and personal usage habits, the actual experience may be different;
9. The heat dissipation capacity data comes from official laboratory calculations, and the heat dissipation performance is based on official laboratory calculations. Due to different factors such as network environment and personal usage habits, the actual experience may vary;
10. The screen of OnePlus 11 is a 6.7-inch Samsung Display AMOLED screen with a refresh rate of 120Hz and a resolution of 3216 X 1440. The screen fluency and battery life experience may be affected by factors such as network, usage time limit, power consumption and brightness. Please refer to the actual experience;
11. The three rear cameras of OnePlus 11 are 50 million + 48 million + 32 million pixels. The shooting effect is affected by shooting technology, ambient brightness and other conditions. Please refer to the actual experience. Hasselblad natural color optimized to professional mode DNG format certified by Hasselblad;
12 and 13 channel multispectral sensor data are provided by the supplier, please refer to the actual experience;
13. OnePlus 11 can support up to 100W charging. The maximum output power is 100W, and the maximum rated power of the standard power adapter is 100W. OnePlus 11 uses 2*2500mAh dual batteries in series (2500mAh is the typical value of single battery capacity), and the typical capacity is equivalent to 5000mAh battery energy. The charging time data comes from the official laboratory report. The test model: OnePlus 11, wired from 1% to 50% in about 10 minutes, and from 1% to 100% in 25 minutes. Test environment: initial battery temperature 25±1°C , ambient temperature 25±1°C. Test conditions: Close all background running programs, turn on the airplane mode, and use the standard power adapter to charge with the screen off when the phone's power is 1%. The actual charging speed may vary due to different device usage, charging conditions and other factors; the test data is for reference only, and the actual experience shall prevail;
14. The battery life is 1600 charge and discharge cycles compared to 800 charge and discharge cycles in the industry. The actual test battery has a remaining capacity of more than 80% after 1600 complete cycles (full charge and discharge). According to the official laboratory simulation user's daily use environment test (full charge and discharge once a day), it is approximately equivalent to 4 years of use. The data comes from official laboratories and may vary due to different test equipment and environments. The actual experience may be different due to the actual usage and habits of individuals;
15. The fluency experience of system use may be affected by environmental factors such as usage time limit, power consumption and brightness. Please refer to the actual experience. The interface content of the above products (including but not limited to UI, background, and data) is only for function display, please refer to the actual version function and interface.
disclaimer
- The above pictures and data are provided by official laboratories or suppliers and are for reference only. Please refer to the official website for all actual experience and detailed remarks;
- The above pictures and functions involve software content, and ColorOS 13 shall prevail;
- Due to real-time changes in product batches and production and supply factors, in order to provide accurate product information, specifications, and product features as much as possible, OnePlus may adjust and revise the text expressions and picture effects on the above pages in real time, so as to be consistent with the actual product Performance, specification, index, parts and other information match; if there is a need to modify and adjust the page, no special notice will be made;
- The size and weight of the mobile phone may vary depending on the configuration, manufacturing process and measurement method, please refer to the actual product;
- Some game screens are authorized from the mobile game "Peace Elite".
This product has passed China RoHS conformity assessment
