name MEIZU 20 INFINITY EDITION

width 73.38mm

height 163.44mm

thickness 8.2mm

weight 215g

battery 4800mAh (typical)

capacity 12GB + 256GB / 12GB + 512GB / 16GB + 1TB （LPDDR5X + UFS4.0）

color Stellar Black / Space Silver / Nebula Green

size 6.79 inches

Screen ratio 21:9

resolution 3192 x1368

contrast 6000000:1

PPI 512

brightness 600nit (typical) 1250nit global maximum brightness

brightness 1850nit local peak brightness

Manufacturing process On-Cell Full Lamination

Qualcomm's second-generation Snapdragon ® 8 mobile platform

TSMC 4nm process

Kryo Prime architecture

3.2GHz maximum frequency

Adreno™ 740 graphics processor

Qualcomm AI Engine

Qualcomm Spectra™ 3 Image Signal Processor

Up to 16GB LPDDR5X full HP memory

Up to 1TB UFS 4.0 ultra-fast flash memory

Rear camera

Main camera/wide angle: 5000 million pixels + ƒ / 1.75 + equivalent focal length 23MM+7 lens

Ultra-wide/macro: 1200 million pixels+ƒ/2.2+equivalent focal length 13mm+6-element lens

Secondary camera/telephoto: 1200 million pixels+ƒ/1.98+equivalent focal length 50mm+6 element lens

120° ultra-wide angle

2.5cm ultra-macro

DarkVision is the ultimate night view

Tetracell pixel 4-in-1

4K 120 fps time-lapse

The ultimate night view

Deeply focused

8K video recording

Dual OIS optical image stabilization system

All-scene EIS video stabilization

Front-facing camera3200 million pixels+ƒ/2.4

5P+1T type lens

T-Len Bionic Human Eye System

Backlit selfie HDR

Super night view in front

Face recognition unlocking

capacity 4800mAh (typical)

specification 5V3.5A or 10V3.5A or 20V3.25A

agreement PD, PPS, QC4.0, Super mCharge (Meizu proprietary protocol)

Wireless charging It supports up to 50W 10W wireless reverse charging

specification External stereo sound

quantity Dual speakers

Open version of all Netcom GSM：B2/B3/B5/B8

CDMA：BC0

WCDMA：B1/B2/B4/B5/B8

TDD-LTE：B34/B38/B39/B40/B41/B42

FDD-LTE：B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B26

NR: n1/n3/n5/n7/n8/n28a/n38/n40/n41/n66/n77/n78/n79

OperatorsSupport China Mobile / China Unicom / China Telecom / China Radio and Television

Mobile data B1/B3/B40/B41/N1/N3/N41/N77/N78/N79

Downlink 4×4 MIMO

WiFi 802.11a/b/g/n/ac/ax/be

Support 2.4G/5G dual-band Wi-Fi support

2×2 MIMO dual antennas

Bluetooth 5.3

GPS (Dual-Band L1+L5)

A-GPS

Beidou

Glonass

Galileo

Accelerometer / Proximity sensor / Light sensor / Electronic compass (geomagnetic) / Gyroscope / Barometric pressure sensor / Front color temperature sensor (display) / Flicker sensor

Proximity sensor / light sensitivity / electronic compass

NFC / UWB

Operating ambient temperature0 to 35°C

Storage temperature-20 to 45°C

1. The actual size and weight of the fuselage may vary slightly depending on the assembly tolerance and configuration.

2. The above data is obtained from the extreme environment test in the laboratory, please try to avoid using it for a long time under this condition to avoid causing malfunction or damage to the mobile phone.

3. The patented technology related to this product has been authorized by Qualcomm.
